Description
Optical Fiber Cables
► Colored fibers
► High modulus (self-supporting) strength member
► Good-performance sheath materials
Application
► Both indoor and outdoor cabling
► Suitable for aerial dropping
Features
► Able to be terminated onsite
► Easy for stripping, and splicing, simplified installation and maintenance
► Low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
Fiber
Type :ITU-T G.657A
Cable
| Spec | Outside dimension (mm) | Max. tensi] | le load (N) | Crush resistant(N/10cm) | |
| Short term | Long term | Short term | Long term | ||
| GJXH(V)-l/2/4 | 2.0×3.0 | 120 | 60 | 2200 | 1000 |
| GJXFH(V)-l/2/4 | 80 | 40 | 1000 | 500 | |
| GJXDH-4 | 2.0×4.0 | 200 | 100 | 2200 | 1000 |
| GJXFDH-4 | 80 | 40 | 1000 | 500 | |
| GJYXCH-1/2/4
GJYXFCH-1/2/4 |
2.0×3.0 – 5.3 | 600 | 300 | 2200 | 1000 |
| GJYXDCH-4
GJYXFDCH-4 |
2.0×4.0 – 6.3 | ||||
Sheath
Material : LSZH, etc.
Temperature Range
| Operating | Transportation & Storage | Installation |
| -20~+60 °C | -20~+60°C | -10~+50°C |
Remark: All values above can be customized
