Description
Optical Fiber Cables
► Colored fibers
► High modulus strength member
► (Non-)Metallic tape armored sheath materials
Application
► Both indoor and outdoor cabling
► Drop in duct
Features
► Able to be terminated onsite
► All-dry structure, facilitating clean installation and ensuring safe and reliable installation
► Low-bend-sensitivity fiber provides excellent communication transmission property
Fiber
Type: G.651, G.652, G.655, G.657, etc.
Cable
| Spec | Outside diameter (mm) |
Max.tensile load(N) | Crush resistant(N/10cm) | ||
| Short term | Long term | Short term | Long term | ||
| GJYX(F)H03-l/2/4 | 5.8 | 600 | 300 | 1000 | 300 |
| GJYXD(F)H03-4 | 6.8 | ||||
| GJYX(F)H53-l/2/4 | 7.8 | ||||
| GJYXD(F)H53-4 | 8.8 | ||||
| GJYX(F)H63-l/2/4 | 6.8 | ||||
| GJYXD(F)H63-4 | 7.8 | ||||
| GJYX(F)HA-1/2/4 | 6.5 | ||||
| GJYXD(F)HA-1/2/4 | 7.5 | ||||
Sheath
| Inner | PVC, LSZH etc. |
| Outside | LSZH, PE etc. |
Temperature Range
| Operating | Transportation & Storage | Installation |
| -20~+60 °C | -20~+60°C | -10~+50°C |
Remark: All values above can be customized
